Site record drawings of Taylor's south-east Transfer Office, 8 December 1817 (2)

Aspect

10 Three perspectives showing different parts of the foundations 11 Perspective showing part of the foundations

Inscribed

10 The foundation under / the Stove in the centre / of the £4 P cent office with the / part of the floor round it, Water-Pipe on the West / side of the old £4 P cent office, Stone (twice), Drain, Pavement and some dimensions given 11 Bank and Water pipe

Signed and dated

(10) Taken Decr. 8th. 18[17] (11) Taken Decr. 8th. 1817

Hand

Soane office

Notes

The three perspectives of drawing 10 show first, the foundations under the stove in the centre of the office, second, part of wall foundations with plumbing and third, the base of a fluted column with brick foundations exposed. Soane re-used many of the foundations of Taylor's old offices but strengthened them.

Drawing 11 shows the three perspectives of drawing 10 in the context of their surroundings. The stove foundations are shown to the left of the drawing, the column base foundations are in the centre and the wall foundations with plumbing behind are shown to the right.
