Reference number

SM (3) 12/1/4 (4) 12/1/5 (5) P 105

Purpose

Record drawings of alternative designs for a four-columned triumphal arch (2)

Aspect

3-5 Perspectives looking east

Inscribed

3 View of a Design for the North front of the Bank of England_ 1803 4 View of a Design for the North front of the Bank of England 5 (upper case) Bank of England NW Angle

Signed and dated

(4) Lincolns Inn Fields Feby 9^th 1804 (sic, See Notes) (5) (frame) Sir J Soane 1803

Hand

(3-5) Joseph Michael Gandy

Watermark

(3) James Whatman Turkey Mill Kent 1799

Notes

Drawing 3 shows the north screen wall largely as executed. The north-west corner has a triumphal arch with a gated entrance. The attic consists of a pedestal crowned with a scrolled acroterion enclosing a scallop shell above a semicircular niche fronted by an urn. Panelled pilasters project project slightly from the sides of the pedestal. Sculpted couchant lions lie on plinths above the angled Corinthian columns. A frieze with a fleur-de-lis motif runs above the arch (as it does in drawing 4).

Drawings 4 and 5 both show the north screen wall with a four-columned triumphal arch framing an apsidal niche with a statue of Britannia. The attic above has a semicircular opening surmounted by a domed cap with a finial. Drawing 3 is dated February 1804 but it is clear that the design it shows was made one year earlier. Drawing 5 is dated 1803. As in drawing 3, the attic is crowned with an ornate scrolled acroterion and fronted by an urn. In the centre of the main arch, a statue of Britannia seated between two lions is raised on a podium; caducei decorate the spandrels of the arch. The drawing shows the north-west corner within a low railing.

Level

Drawing
