Reference number

SM (43) 10/1/40 (44) 10/1/39

Purpose

Presentation drawings for removal of the gateway on Bartholomew Street, one dated 15 September 1796 (2)

Aspect

43 Elevation from Bartholomew Street showing gateway and screen wall built by Robert Taylor and, to the north, the screen wall built by Soane 44 Elevation from Bartholomew Street omitting gateway and adjacent ornamentation and including blind Tivoli windows; (verso, pencil) perspective of rounded corner of wall with 'portico' in antis

Scale

(43) bar scale (44) to a scale

Inscribed

43 Return Wall in Bartholomew Lane, The Bank of England, 44 dimensions given, (Bailey) The Bank of England, Design for part of the East Front

Signed and dated

(43) Sepr 15th 1796 (44) (Bailey) 1795

Hand

Soane office

Notes

On 1 March 1797 the Bank Building Committee approved Soane's plan for continuing the new screen wall and taking down the present gateway on Bartholomew Lane.

Level

Drawing
