Reference number

SM D1/4/50

Purpose

Stratton Park, Hampshire, 1803-07

Aspect

[140] Plan of N end of library showing the folding door and radius of curved bookcases

Scale

1 in to 1 ft

Inscribed

labelled Center line of Library, Wall Line (six times), dimensions given and (verso, Dance) Stratton / Part of Plan of Library

Signed and dated

1803-07

Medium and dimensions

Pen on laid paper (840 x 670)

Hand

neat printed office hand (same as [SM D1/1/10] and [SM D1/1/7]

Watermark

D & C Blauw IV and D&CBxX in cartouche surmounted by fleur-de-lis

Notes

The two corners of the north end of the library have bookshelves fitted so that a gentle radius is produced and the uprights of the shelving are splayed so that the books can stand parallel.

Level

Drawing
