[7] Design for the principal elevation of a castellated house, 1783, executed to a variant design
Browse
Reference number
SM Adam volume 48/30
Purpose
[7] Design for the principal elevation of a castellated house, 1783, executed to a variant design
Aspect
Elevation of a three-storey building, same as SM Adam volume 48/29 with the addition of crenellations and machicolated cornices to the round towers
Scale
bar scale of 1 inch to 10 feet
Inscribed
Lord Templeton[sic]
Signed and dated
- 4/7/1783
Adelphi / 4h July 1783
Medium and dimensions
Pen and pencil on laid paper (436x261)
Hand
Possibly
Adam office hand, possibly Robert Morison
Adam office hand, possibly Robert Morison
Literature
Bolton, 1922, p. 6
For a full list of literature references see scheme notes.
For a full list of literature references see scheme notes.
Level
Drawing
