  • image SM Adam volume 2/135

Reference number

SM Adam volume 2/135

Purpose

Preliminary design for a rustic building, ND

Aspect

Above - Elevation of a single-storey, three-bay building with a thatched, hipped roof and a central Doric portico. The portico is flanked by half-height windows, with projecting, socle-shaped lintels above Below- Plan of a four-by-one-bay building, with a colonnaded screen. Within there is a central two-bay room and this is flanked by single-bay rooms

Scale

to a scale

Inscribed

10 / 2 (crossed through) (pencil)

Signed and dated

  • ND
    ND

Medium and dimensions

Pen and pencil on laid paper (226x193)

Hand

Probably Adam, Robert (1728--1792), architect
Robert Adam

Level

Drawing
