You are here: CollectionsOnline  /  Preliminary alternative designs for the south entrance, 16 May 1805
top left corner
top right corner
bottom left corner
bottom right corner
image Image 1 for SM (3) 1/7/14
image Image 2 for SM (3) 1/7/14
  • image Image 1 for SM (3) 1/7/14
  • image Image 2 for SM (3) 1/7/14

Reference number

SM (3) 1/7/14

Purpose

Preliminary alternative designs for the south entrance, 16 May 1805

Aspect

3 Two rough part-elevations of the entrance, showing Doric columns and entabalture supporting a pyramid of cannon-balls; (pencil) rough elevation of paired Doric columns supporting an entablature; (verso) rough elevation of Doric entablature with smaller cornice, surmounted by a pyramid of cannon-balls

Scale

bar scale

Inscribed

The Bank, Sketch of Entablature to Porch of Intended Barracks, elevation labelled (Soane): Qy height / of Cill to / wind[ow] --- (illegible) and dimensions given

Signed and dated

May 16: 1805 (verso) May 17: 1805

Hand

Soane

Notes

Drawing 3 shows three alternative designs for the entablature of the south elevation. The angle of the cornice varies, as does the proportion of the cornice within the entablature.

Level

Drawing

Digitisation of the Drawings Collection has been made possible through the generosity of the Leon Levy Foundation

If you have any further information about this object, please contact us: drawings@soane.org.uk

Sir John Soane's collection includes some 30,000 architectural, design and topographical drawings which is a very important resource for scholars worldwide. His was the first architect’s collection to attempt to preserve the best in design for the architectural profession in the future, and it did so by assembling as exemplars surviving drawings by great Renaissance masters and by the leading architects in Britain in the 17th and 18th centuries and his near contemporaries such as Sir William Chambers, Robert Adam and George Dance the Younger. These drawings sit side by side with 9,000 drawings in Soane’s own hand or those of the pupils in his office, covering his early work as a student, his time in Italy and the drawings produced in the course of his architectural practice from 1780 until the 1830s.

Browse (via the vertical menu to the left) and search results for Drawings include a mixture of Concise catalogue records – drawn from an outline list of the collection – and fuller records where drawings have been catalogued in more detail (an ongoing process).
