Record drawings, September 1796 (2)


3-4 Plan and elevation


to a scale (smaller than drawings 1-2)


4 (Soane) Design for a Mausoleum / The principal Front

Signed and dated

  • (3) (pencil) Seward and Sept 22d 1796 (4) (pencil) Smirke and Septr 20th 1796

Medium and dimensions

Pen, light red wash, pencil; pen, sepia washes, pencil, shaded on laid paper (368 x 232, 232 x 368)


Henry Seward (pupil, from May 1794), Robert Smirke (1796-7)


3 fleur-de-lis


While the plan is the same as the one shown on drawing 1, the elevation has a few additions to that of drawing 2. It is now furnished with four alcoves, four niches, eight tablets and four small cinerary urns as well as the pedestals supporting trophies also shown on drawing 2. Presumably Smirke did this at Soane's direction - both plans indicate two alcoves on this front.
Henry Hake Seward (1778-1848) was articled to Soane in May 1794, remained in Soane's office after his articles had expired and left in 1808. Robert Smirke (1780-1867) entered Soane's office in May 1796 but left after a few months 'owing to a mutual antipathy between master and pupil' (H.Colvin, Biographical dictionary of British architects 1600-1840, 3rd ed., 1995).
Margaret Richardson (note, February 2008) comments that drawing 3 seems to be in the same hand as drawing 1, and drawing 4 in the same hand as drawing 2 - hence the attributions of 1 and 2.
